Super Light Weight & Compact Size
Aluminum CNC Cooling Case
High Stability & High Efficiency & High Sensitivity
Easy Adjustment With Dual Gain
Competition Grade Drifting
Specification
Item Name: G3
Shell Material:AL6061
Weight:4g
Dimension:21*15*8.8mm
Operating Voltage:3.7~8.4V
Current Drain:20mA/6V
Dual Gain Mode: Normal/ Sensitive Mode
Operating temperature: -10℃+50℃
Control System: PID Control System
Output Signal: 1520uS(50Hz/333Hz) / Sanwa SSR
Input Signal: PWM(50-333Hz) / Sanwa SHR/SSR / Futaba S.Bus
Input & Output Plug: JST1.5mm(attached the signal input cable to connect with receiver)
